Voltage/ Frequency
220-240V | 50/60 Hz
Heated water temperature ( ํC)
> 85 ํC
Heating Method
External heating Element
Hot Tank dimension (ID x length) (mm.)
No hot water
Heated water capacity min at 25 ( ํC) Ambient (L/hr)
No hot water
Water bottle position
SUS304
Chilled water temperature - normal ( ํC)
≤10 ํC
Cold Tank dimension (ID x length) (mm.)
φ100 x155 (3L)
Cooling Method
Compressor
Refrigerant type and weight
R134a/28g
Chilled water capacity min at 25 ( ํC) Ambient (L/hr)
2.5 L/H
Cold water tank material
SUS304
Dimension (WxDxH) (mm.)
310 x 360 x 1000
Net Weight (kg.)
15.2 Kg.
Product Warranty
2 year product warranty , 5 years compressor warranty
Remark
Specifications are subjected to change without prior notice and responsibility due to an error in the typing in anyway.
